Abstract
In the presence of antigen and costimulation, T cells undergo a characteristic response of expansion, cessation and contraction. Previous studies have revealed that populationlevel reproducibility is a consequence of multiple clones exhibiting considerable disparity in burst size, highlighting the requirement for singlecell information in understanding Tcell fate regulation. Here we show that individual Tcell clones resulting from controlled stimulation in vitro are strongly lineage imprinted with highly correlated expansion fates. Progeny from clonal families cease dividing in the same or adjacent generations, with interclonal variation producing burstsize diversity. The effects of costimulatory signals on individual clones sum together with stochastic independence; therefore, the net effect across multiple clones produces consistent, but heterogeneous population responses. These data demonstrate that substantial clonal heterogeneity arises through differences in experience of clonal progenitors, either through stochastic antigen interaction or by differences in initial receptor sensitivities.
Introduction
Tcell immunity against infection requires the activation and expansion of a small number of pathogenspecific cells to form a larger pool of protective lymphocytes^{1}. The net behaviour of these rare pathogenspecific clones dictates the characteristics of the population response and, for a given infection, results in a highly reproducible response magnitude. Despite this consistency in population responses, in vivo measurements of clonal burst size and phenotype have revealed substantial heterogeneity between clones^{2,3,4,5,6,7}, highlighting the requirement for singlecell information in understanding Tcell fate regulation. From these studies, a critical question arises: how is clonal diversity within the Tcell response generated? In particular, to what extent is variation in clonal outcomes intrinsically inherited from the initial cell and how much arises through deterministic and stochastic processes, both intrinsic and extrinsic, experienced by individual daughter cells after the initial activating events^{8}? Here we direct this question to examine the considerable variation in proliferative capacity of individual T cells following stimulation^{2,3,4,5}.
Populationlevel studies have demonstrated that T cells with identical Tcell receptors (TCRs) respond heterogeneously^{9,10,11} and, even under controlled in vitro conditions^{9}, divide a variable number of times before stopping and reverting to a quiescent state. Following previous studies^{9,12,13}, we defined the generation in which an activated lymphocyte returns to quiescence to be its division destiny (DD) and asked how heterogeneity in DD is generated at a family level. Figure 1 presents two alternative clonal level possibilities: first, the population distribution of DD (Fig. 1a) could arise through strongly clonally correlated DD fates; and, second, the heterogeneity might emerge from highly discordant family DD histories (Fig. 1b top and bottom panels, respectively). Identifying strong clonal concordance would indicate that DD is a lineage primed, inherited property. In contrast, clonal discordance in DD fate, in which cells stop over multiple generations, could result from deterministic programming through an asymmetric cell division^{14,15} or by stochastic regulation^{16,17}. Published data cannot distinguish between these possibilities.
Any clonal level answer to the question of relative concordance in DD must also be reconciled with a further striking population level observation: Tcell DD is regulated by the type and the strength of the signals received, and many signal combinations result in both the means and variances of population DD distributions summing linearly, illustrated in Fig. 1c (ref. 9). This observation suggests independence of the effects of signals driving DD. Thus the solution to the familial genesis of DD variation posed in Fig. 1a,b must also address how variable outcomes at single cell level result from fates of clonal family trees (Fig. 1d). Here we sought to identify the source of DD variation, and identify how signal integration that is additive at the population level results from, and is consistent with, clonal family behaviour. To address these questions we develop and utilize a novel multiplex clonal divisiontracking assay based on the combinatorial use of multiple division tracking dyes. Using this technique we reveal that CD8^{+} Tcell clones are imprinted with highly correlated division fates during the early immune response, such that progeny cells from clonal families cease dividing in the same or adjacent generations, with interclonal variation producing burstsize diversity. We report a new mathematical framework enabling us to deduce that the summation of Tcell stimuli effects on division number at the clonal level are stochastic and independent. This clonal addition of signals results in reproducible populationlevel responses, with substantial clonal heterogeneity arising through differences in stochastic antigen interaction and initial receptor sensitivity.
Results
A novel multiplex assay to measure clonal division
To investigate clonal regulation of Tcell DD, we developed a method to determine familial proliferation features of a large number of founder cells. To simultaneously track proliferation of multiple clonal families in a single culture well, we labelled lymphocytes with quantitatively distinct combinations and concentrations of the division tracking dyes 5(and 6)carboxyfluorescein diacetate succinimidyl ester (CFSE), CellTrace Violet (CTV) and Cell Proliferation Dye eFluor670 (CPD) (Fig. 2a,b)^{18,19}. In this way we created up to 10 fluorescently distinct populations in a single coculture. To measure clonal regulation of division fate using this multiplex tracking dye method, we adopted the minimal in vitro stimulation system that was established previously to determine variation in DD at a population level (as in Fig. 1a)^{9}. OTI CD8^{+} T cells, which recognize SIINFEKL (N4) peptide presented on H2K^{b}, and deficient for the proapoptotic protein Bim (OTI/Bcl2l11^{−/−}) were purified, labelled with the division tracking dye multiplex and stimulated by peptide selfpresentation in the presence of antimouse IL2 blocking antibody (clone S4B6; Fig. 2a–c). Bimdeficiency enhanced cell survival without altering DD and addition of antimouse IL2 blocking antibody limited the autocrine IL2 present in the culture, allowing T cells to reach DD within the range of division tracking dyes^{9}. After 26 h (just prior to the first division) cells were sorted so that a single stimulated but undivided cell, identified by high forward scatter (FSC) fluorescence and undiluted division tracking dye, from each fluorescently distinct population was sorted per well. Cells were returned to culture, without peptide but with S4B6, until analysis by flow cytometry at 54, 62 and 72 h post stimulation (Fig. 2d,e), capturing times when most cells were reaching DD without considerable cell death having occurred^{9}. Clonal family division fate from each labelling configuration was identified using the fluorescent gating scheme outlined in Fig. 2f. Small cell size was used to indicate return to quiescence, as previously defined by correlation with a cell cycle reporter of G_{0} (refs 9, 12, 20; Fig. 2f, also Supplementary Fig. 2, and Methods).
Assessing synchronicity in clonal Tcell proliferation
Figure 3a–c and Supplementary Fig. 3 displays results of an application of the multiplex clonal stimulation assay to OTI/Bcl2l11^{−/−} CD8^{+} T cells stimulated by N4, αCD28 and IL2 (added as human IL2 (hIL2) to overcome blocking by S4B6). Fig. 3a presents a population control culture where 500–2,000 cells were sorted from each of eight labelled groups, stimulated and harvested at 72 h post stimulation. As described in Fig. 2, the data in Fig. 3a enabled the identification of generationgates for each dyecombination. Fig. 3b shows two single cocultured wells harvested at the same time, with the populationdetermined gates overlaid, allowing the determination of the generation of each individual cell in each clonal family. These data illustrate how the multiplexing system permits distinct families to be isolated and followed in the coculture, empowering analysis of familial concordance under these, and altered, culture conditions.
Tcell proliferation is synchronous
The data shown in Fig. 3c was analysed for features of clonal proliferation synchronicity. From an input of 224 clones across three time points, we detected at least one progeny cell from 171 clones (76% of the input). In 42% of these clones, all progeny cells were measured, which is comparable to the recovery from timelapse microscopy of nonadherent cells^{12}. The proportion of cells per generation from the pooled clonal progeny and population control were comparable (Supplementary Fig. 4).
Clonal Tcell division progression was notably concordant (Fig. 3c, Supplementary Fig. 3). At 54 h a considerable proportion of the clones were still dividing (blue), with more quiescent progeny cells (red) being found at 62 and 72 h. Irrespective of time point or quiescence status, the progeny of an individual clone exhibited strongly synchronous proliferation, with the progeny of 85% of clones being detected in the same generation. In all remaining clones, progeny were detected in adjacent generations (Fig. 3c). This was also observed under conditions when peptide persisted in the culture (Supplementary Fig. 5), and was consistent with previous observations of a high degree of synchrony in T and Bcell sibling and cousin division times^{12,20,21,22}. In all mixed phenotype clones, the dividing progeny were found in the same or previous generation compared with the quiescent cells (Fig. 3c, Supplementary Fig. 3). This suggested that the discordance observed arose through slight variations in division timing or potential within an otherwise synchronized clone, consistent with Fig. 1b, upper panel.
Division fate is concordant in response to different stimuli
For this Tcell system, it has been shown that population level DD is strongly influenced by a range of signals that act alone or in concert to extend the number of mitotic cycles cells undergo^{9}. To add to the N4+αCD28+IL2 data presented in Fig. 3, we set up conditions to examine concordance with N4 alone, N4+αCD28, and N4+IL2, added as hIL2. To determine clonal DD for each condition, we pooled data from 54, 62 and 72 h for families where all detected progeny were quiescent (Fig. 4a, Supplementary Fig. 6a). To summarize the concordance of a clonal family we measured the difference in generation number between the greatest and least DD of any descendant of a clone, a quantity we called the range. Fig. 4b and Supplementary Fig. 6b plots the distribution of range for each culture condition, illustrating that for the vast majority of families perfect concordance is observed.
Clonal family DD is concordant
While superficially the data indicate strong familial features for each stimulatory condition, we sought to quantitatively investigate how much withinfamily correlation in DD fate was necessary to explain the data in Fig. 4b, taking into account that the experimental method does not sample all cells. To that end, we developed a stochastic model of family DD construction based on statistics from the data in conjunction with a single tunable parameter that describes the correlation in DD decision of cells within a family. For each condition, data was pooled across families and the number of cells, n_{k}, observed to have undergone DD in each generation k recorded. From these data, the proportion of cells, p_{k}, that did not undergo DD in generation k was determined taking cohort correction into account
If cells within a family made independent DD decisions, a binomial number of them, with probability p_{k} would be observed to progress without experiencing DD to generation k+1. To capture withinfamily correlated DD fate, the longestablished correlated generalization of the binomial distribution, the betabinomial distribution, was employed. This distribution is parameterized by the probability of progression, p_{k}, and a value ρ∈[0,1] that captures the correlation in the fate of each pair of cells within a family in the same generation. If ρ=0, then all clonal cells make independent DD decisions to progress to the next generation with probability p_{k}. If ρ=1, then all clonal cells in each generation share a single DD decision to progress to the next generation with probability p_{k}. As ρ ranges from 0 to 1, this dependency is interpolated. The proportion of cells across multiple families that progress from one generation to the next is determined by , irrespective of the value of ρ.
Given , defined by a stimulation condition, and a correlation ρ, the induced probability distribution on full presampled DD trees was determined (see Methods). Each cell from a full clonal family is sampled independently with a probability determined either by the percondition average proportion of beads recovered per well (Fig. 4c) or the average per well volume measured (Supplementary Fig. 6c), from which we computed the sampledtree range distribution (see Methods).
For a variety of values of ρ, including the percondition maximum likelihood estimate, the resulting distribution of range was determined. With 95% confidence intervals based on the number of families that are experimentally recovered (see Methods), Fig. 4c displays the range distributions that arise from this model overlaid with the experimental data. For all conditions, a substantial correlation of ρ≥0.8 is necessary to recapitulate the data and, in particular, the range data is not consistent with a familyindependent DD mechanism.
Signal integration effects on clonal division fate
The above analysis indicates that clonal DD is a strongly inherited, concordant property within a family lineage under a range of culture conditions. Given this conclusion, we turned our attention to the question of how signal addition at the single cell level operates. Results from signal addition studies at the population level provide a hypothesis^{9} as the reported summation had an additive effect on both the mean and variance of the population DD distribution. When the implications of these observations are considered at the family level, this finding suggests that signal integration at the clonal level might be stochastically independent. That is, each signal is responsible for heterogeneous levels of expansion and the Tcell clones independently integrate each signal. To test this prediction, we further interrogated the data presented in Fig. 4.
Stimuli effects on clonal division fate add independently
To enable quantitative comparison between the expansion effects of distinct stimuli in combination, we developed a new theory for the addition of family trees, presented in detail in Methods. The most significant consequence of our mathematical analysis is that in order to determine the generations in which cells become quiescent in a concatenated tree, it is sufficient to know how many cells become quiescent in each generation in the trees to be added (Fig. 1d, Supplementary Fig. 1 and Methods). This feature allows us to address questions of signal integration using data from the multiplex clonal proliferation assay, which does not provide entire family tree structure. Moreover, determination of the generations in which cells are quiescent in the final tree does not depend on how the participating trees are interlaced in the addition procedure (Supplementary Fig. 1 and Methods). This indicates that the mathematics is suitable for describing simultaneous application of mitogenic stimuli, as the DD outcome is invariant to the order of their impact.
For each stimulation condition, we first summarized the DD information of each clonal family with two expansion statistics, the maximum DD (maxDD), that is, the greatest generation observed in a quiescent family, and the cohort normalized mean DD (mDD) (see Methods). The empirical cumulative distributions of these statistics are plotted in the left panels of Fig. 5a and b, respectively. Crucially, in the framework of tree concatenation both maxDD and mDD are linear operators. Consequently, if signal integration were independent, then the distribution of the maxDD or mDD determined from data generated by two stimuli would necessarily coincide with the convolution of the distributions generated by each stimulus alone. In particular, if the influence of αCD28 and IL2 on DD were independent, with no more than one of them correlated to the N4 effect, then the distribution of the sum of the maxDD or mDD statistics of (N4+αCD28) and (N4+IL2), which is the convolution of those two distributions, would correspond with the distribution created from the sum of (N4) and (N4+αCD28+IL2). As shown in the right panels of Fig. 5a and b, respectively, these convoluted distributions align remarkably well (see also, Supplementary Fig. 7). In order to test the statistical hypothesis that the convolutions are independent it was necessary to create a nonstandard test based on previous results (explained in Methods), giving P values of 0.399 and 0.237 for maxDD and mDD, respectively, and thus the hypothesis of independent additivity of αCD28 and IL2 is not rejected.
Signal sensitivity regulates clonal family DD
Taken together, the combination of strong clonal concordance in DD and independent additivity of signals traces a large component of DD fate programming to the initial founder cells. Thus we speculated that variation in clonal fates might be traced to measurable differences in levels of cellular components associated with signal perception. In particular, for signal integration to be independent at the clonal level, we reasoned that receptor levels for different signals would be uncorrelated in activated cells. If this were not correct, we expect correlated receptor levels would lead to dependence of signal strength between costimuli, which was not observed.
To identify possible sources of individual founder cell variation we asked whether differences in critical receptor levels for the stimuli tested in Figs 2, 3, 4, 5 correlated with subsequent family clone size. CD28 and interleukin2 receptor chain alpha (IL2Rα) levels just prior to the first division were relatively uniform (Supplementary Fig. 8) (Spearman’s correlation of 0.16), supporting the finding of independence of signal effect on DD in clonal families. To investigate if CD28 levels influenced DD, we sorted naive OTI/Bcl2l11^{−/−} CD8^{+} T cells into CD28 high (CD28^{hi}) and low (CD28^{lo}) expressing populations (Fig. 6a) and measured the effect on mDD. Residual αCD28 antibody from sorting had little effect on cell expansion (open circles, Fig. 6b–d). When αCD28 was added to the culture the CD28^{hi} population had a ∼0.6 division increase in mDD relative to CD28^{lo} cells (black arrow, Fig. 6c,d), resulting in an ∼50% increase in cell expansion (closed circles, Fig. 6b,c). Thus, differences in initial CD28 receptor level exhibited by the naive Tcell population did contribute to the founder cell variation in DD.
In contrast, sorting for IL2Rα high (IL2Rα^{hi}) and low (IL2Rα^{lo}) levels prior to first division (Fig. 6e) gave a shift of ∼0.73 divisions in mDD irrespective of whether IL2 was present in the culture (Fig. 6f–h). As IL2Rα is regulated by the strength of TCR stimulation^{11,23,24}, the difference in expression between IL2Rα^{hi} and IL2Rα^{lo} cells likely reflects intrinsic differences in cellular TCR stimulation strength due to stochastic antigen encounter, consistent with the observation that TCR stimulation strength regulates DD^{9}.
The observation that mDD in this system was not affected by IL2Rα level, but was altered by the ligand IL2, implies that within the range of IL2Rα levels found in the stimulated population transmission of signal was not limited by this component of the multisubunit receptor. We suggest this result is explained by previous studies that demonstrate the IL2Rα expression is in excess and far exceeds the number of IL2Rβ and γ chains, the receptor units required to transmit IL2 signals^{25,26}. Given this conclusion, IL2Rα expression would not affect the independence of IL2 signal integration with other coreceptors. Thus uncorrelated signal integration is dependent not only on the receptor levels, but the degree to which this variation changes signal sensitivity.
The conclusion that DD fate identifies with IL2Rα and CD28 expression levels before first division is further illustrated in Supplementary Fig. 9. OTI/Bcl2l11^{−/−} CD8^{+} T cells were sorted for CD28^{hi} expression (top 20%), stimulated by N4 selfpresentation, then sorted at 26 h for IL2Rα^{hi} (top 35% of population) and monitored for 72 h in media supplemented with hIL2. The variation in division fate in these cells was compared with that of an unsorted population control. As predicted, sorting significantly reduced the variation in DD outcomes, with a reduction in the population variance from 1.3 to 0.67.
Discussion
Cellular replication is a simple, effective mechanism for generating a large number of antigenspecific clones from rare precursor cells. During an acute response in vivo a CD8^{+} T cell can divide up to 15–20 times^{27,28,29} and give rise to numerous classes of effector and memory cell types, all with identical antigen receptors. In vivo singlefamily tracking studies have revealed significant heterogeneity in the family size of identical cells and a strong concordance in familial differentiation fate^{2,3}. Other studies have ascribed variation in fates to early division bifurcations, and numerous extrinsic signals known to influence the pattern of Tcell regulation^{14,15,30}. Thus, the relative contribution of extrinsic and intrinsic differences to the fate of otherwise identical cells following stimulation is currently of great interest.
We sought to gain insight into this question by investigating the genesis of heterogeneity following stimulation of apparently identical T cells placed under controlled stimulatory conditions. To do so we have introduced a novel multiplex clonal divisiontracking assay based on the combinatorial use of division tracking dyes. This method allowed us to detect cell division fate of clonal families of identical TCR transgenic T cells for up to 6–7 generations using the singlecell technology of flow cytometry.
We applied this method to examine the clonal influence on variation in DD, the generation at which a stimulated cell returns to a quiescent state, a feature known to be highly variable within a population of stimulated cells^{9,12,13}. The results were unequivocal: our experiments revealed progeny cells from clonal families ceased dividing in the same or adjacent generations with high probability, identifying interclonal variation as the principle source of DD diversity under these conditions. This conclusion for T cells aligns with earlier results from Bcell filming that revealed similarly strong concordance in family DD after stimulation by the tolllike receptor agonist CpG DNA^{12}. Together these data lead us to a general hypothesis: that stimulation of a resting T or B cell initiates an intrinsic sequence of symmetric divisions with an automated return to quiescence.
Our investigation of DD highlights strong familial concordance raising the question of how branches or discordance might occur. Many studies have shown that Tcell fate is influenced by extrinsic signals^{30,31,32}. The relative contribution of for example, ligands found on an antigen presenting cell (APC) fostering an asymmetry in an early division^{14,33}, or variation in exposure to APC and different antigen experiences as the cells divide will also percolate through to branching changes in family responses. Depending on where alternative signals are experienced, whole families with alternative branching could be created. Our assay is well suited to investigate the contribution of controlled delivery of extrinsic systems especially where direct filming would be technically difficult, as is the case when stimulation is provided by antigen presenting cells or a stromal cell source is necessary.
For T cells, DD is sensitive to costimulatory and cytokine signals, and our multiplex dye method allowed us to assess the manner of signal addition. To do so we developed a new mathematical framework to study the addition, or concatenation, of family trees, as well as developing a novel statistical test to challenge the hypothesis of independent signal integration. Application of these techniques established that the clonal level effects on generation number of summation of Tcell stimuli are consistent with them being stochastic and independent. Given the simplicity of our system, this conclusion allowed us to trace the source of the stochastic heterogeneity in DD to differences in programming of the initial naive cell.
These findings turned our attention to identifying cellular features and molecular determinants that might account for the differences in DD imprinting in each founder cell. Here the results for CD28 were informative. OTI/Bcl2l11^{−/−} CD8^{+} T cells express a broad lognormally distributed range of CD28 on the ‘identical’ population. This variation has significant consequences as the expansion achieved corresponds to the strength of signal integrated and the resulting DD of the cell. The cytokine IL2 is an important contributor to Tcell responses. Our culture system eliminated autocrine IL2 contributions that would likely serve to increase the variation in each family tree as local concentrations develop. Furthermore, our analysis of the receptor indicated a broad distribution following this high affinity stimulation level, but receptor numbers were not limiting for the transmission of the IL2 signal. Published studies show that weaker stimulation leads to lesser expression of the receptor^{11,23,24}. For sufficiently weak stimulation, we expect a point will be reached where the IL2 produced and the receptor level expressed promote variation in DD among similar cells due to changes in local conditions. Examining this possibility requires further in vitro studies, followed by in vivo experiments to determine its functional significance.
Many additional receptors transmit signals that influence the final extent of expansion and division progression including CD27, IL12, IL4, IL2 and IL6 (refs 9, 10, 34, 35). Independent stochastic expression of receptor numbers for each of these ligands would result in a multifactorial complex population, where the experience and fate of every cell would be different even when placed in identical stimulation conditions. As the stochastic drivers of receptor heterogeneity are reproducible, we speculate that the inherent variegation of the initial population, and the mix of different fate allocations, will prove to be consistent and robust. Combinatorial differences in DD fate would result from them and, as differentiation to effector states and memory states has been linked to division progression^{36,37}, this in turn would impact the genesis of different cell types. What, if any, direct influence that these receptor levels have on differentiation programmes warrants further investigation. A combination of the multiplex assay for division tracing described with index sorting would suffice for that purpose.
Our discovery of striking concordance in a controlled in vitro setting raises the question, how much of the CD8^{+} Tcell response during an in vivo infection is driven by an automatous response with multiple concordant family outcomes, and how much is directed by extrinsic influences? Although at this point no direct in vivo observations exist to resolve this question we can interrogate the features of existing clonal and population in vivo data to test whether it would be consistent with the strongly concordant, inherited DD we have observed in vitro. By assuming a familybased DD, our previous in vivo population experiments allowed estimation of the generations in which families reached DD^{9} from which we determined the relative contribution of clonal families to the response magnitude. Comparing this to findings from published in vivo clonal studies^{2,3} we found a quantitatively similar pattern, with a small number of clones generating the bulk of the responding cells (Supplementary Fig. 10a). Based on the family sizes from ref. 2 we could also estimate the DD distribution and found the interclonal DD was spread over ∼10–15 generations, consistent with model fitting to population response data (Supplementary Fig. 10b). Thus, in vivo findings are consistent with a clonally regulated DD, though further studies more directly measuring division fate as well as monitoring simultaneous differentiation changes to effector and memory states associated with clonal cell division are required to complete and formally test our understanding of clonal fate regulation under these complex conditions.
Taken together these findings provide fundamental insight into Tcell fate regulation at the level of the individual clone, and we anticipate they will help lead to predictive models of clonal cell fate regulation. Given the growing importance of anticancer therapies that expand and reinvigorate highly clonal in vitro and in vivo Tcell responses^{38,39}, this better understanding of the fundamental nature and source of the variation in burstsize will facilitate rational optimization of Tcell response manipulation.
Methods
Mice
OTI/Bcl2l11^{−/−} and OTI/FucciRG mice^{9} were bred and maintained under specific pathogenfree conditions in the WEHI animal facilities (Parkville, Victoria, Australia) and used between 6–10 weeks of age. OTI/FucciRG mice were bred from the red (R) FucciG1#639 and green (G) FucciS/G2/M#492 mouse lines. All experiments were performed under the approval of the WEHI Animal Ethics Committee.
CD8^{+} Tcell purification
CD8^{+} T cells were isolated from mouse lymph nodes and spleens by negative selection using EasySep Mouse CD8^{+} Tcell Isolation kit (StemCell Technologies) according to the manufacturer’s protocols. Enrichment of OTI CD8^{+} T cells was confirmed by flow cytometry with a yield of 90–95% CD8^{+}Vα2^{+} lymphocytes.
Labelling with division tracking dyes
OTI/Bcl2l11^{−/−} CD8^{+} T cells were labelled with the indicated combinations and concentrations of the division tracking dyes CTV, CFSE (both Invitrogen) and CPD (eBioscience) in PBS (WEHI media) containing 0.1% BSA (Sigma) (PBS 0.1% BSA) at a density of ≤10^{7} cells ml^{−1} at 37 °C for 20, 10 and 10 min, respectively. The reaction was quenched by washing with 2 × 5 ml icecold RPMI 5% FCS.
In vitro cell culture
Complete tissue culture medium was RPMI 1640 medium supplemented with 10% FCS, nonessential amino acids, 1 mM Sodiumpyruvate, 10 mM HEPES, 2 mM GlutaMAX, 100 U ml^{−1} Penicillin, 100 μg ml^{−1} Streptomycin (all Invitrogen) and 50 μM 2βmercaptoethanol (Sigma). OTI/Bcl2l11^{−/−} CD8^{+} T cells were stimulated with 0.01 μg ml^{−1} SIINFEKL (N4) peptide (Auspep) in 96 well roundbottomed plates by selfpresentation at a density of 10,000 cells per well in 200 μl complete tissue culture medium, as described previously^{9}. All cultures contained 25 μg ml^{−1} of antimouse IL2 monoclonal antibody (supernatant from hybridoma cell line S4B6, WEHI monoclonal antibody facility) that blocks the activity of mouse IL2 in vitro but does not recognize human IL2 (hIL2)^{9}. Recombinant hIL2 (Peprotech) and antiCD28 (clone 37.51, WEHI monoclonal antibody facility) were added to cultures where indicated. Cells were incubated in a humidified environment at 37 °C in 5% CO_{2}.
Cell sorting and flow cytometry
Cell sorting was performed on a FACSAria W or L (BD Biosciences) cell sorter. For IL2Rα and CD28 level sorting, cells were labelled with antiCD28PECy7 (clone 37.51, eBioscience) or antiCD25FITC (clone 7D4, BD).
Flow cytometry was performed on a FACSCanto II or LSRFortessa X20 cytometer (both BD Biosciences). Data were analysed using FlowJo software (Treestar).
A known number of beads (Rainbow calibration particles, BD Biosciences) and propidium iodide (0.2 μg ml^{−1}, Sigma) was added to samples immediately prior to analysis. The ratio of beads to live cells was used to estimate the absolute cell number. The following monoclonal antibodies were used for the detection of cell surface markers: antiCD25 PECy7, or—APC (clone PC61, BD Biosciences) antiCD28PECy7 (clone 37.51, eBioscience). Staining was performed in PBS containing 0.1% BSA and 0.1% sodium azide (Sigma). In Supplementary Fig. 8, activated cells were defined as the 50% of cells with the highest FSC fluorescence. Spearman’s correlation was calculated using Matlab 2011a’s corr function.
Highthroughput clonal multiplex assay to measure DD
Naive OTI/Bcl2l11^{−/−} CD8^{+} T cells were purified and sequentially labelled with CFSE (5, 2.5, 0 μM), CTV (5, 2.5, 0 μM) and CDP (5, 0 μM) (Fig. 2a,b). After the population labelling controls were plated, cells from the 10 labelling combinations indicated in Fig. 2c were pooled together and 10,000 cells were added per well for stimulation with N4 peptide in the presence of S4B6, either with or without antiCD28 (2 μg ml^{−1}, Fig. 2c). After 26 h (just prior to the first division), cells were sorted so that a single stimulated (estimated based upon high FSC fluorescence) but undivided cell from each fluorescently distinct population was sorted into each ‘sample’ well of 96well roundbottomed plates (Fig. 2d). Cells were cultured in the presence of S4B6 either with or without hIL2 (1 U ml^{−1}). Four different stimulation combinations were monitored: N4, N4+αCD28, N4+IL2 and N4+αCD28+ IL2. Cells were collected for analysis by flow cytometry at 54, 62 and 72 h post stimulation. At each analysis time point, 7,500 beads were added to measure sample recovery (>90% of the sample for >90% of the tubes in the experiment shown), and PI (0.2 μg ml^{−1}) for dead cell exclusion. Samples were carefully transferred into 5 ml polystyrene tubes and entire sample was analysed (Fig. 2e).
For data analysis, gates were set using single label configuration population controls then applied to clonal data as shown in Fig. 2f. Briefly, lymphocytes were identified from FSC/side scatter (SSC) profiles and dead cells excluded using PI. Cells were divided into CPD^{−} and CPD^{+} then division gating for each labelling configuration was performed on CFSE versus CTV dot plots. Finally cells were gated as ‘small’ or ‘not small’ from FSC/SSC profiles to classify cells as quiescent or dividing respectively. Small cell size has previously been demonstrated to be a good surrogate of lymphocyte quiescence^{9,12,20}. We further demonstrated this with independent experiments using OTI/Fucci cell cycle reporter mice, in which cells accumulate the FucciRed reporter when they have reverted to a quiescent state, or express the FucciGreen reporter when progressing through the S/G_{2}/M phases of the cell cycle^{9,21,40,41}. OTI/FucciRG CD8^{+} T cells were stimulated in similar conditions to those used in the clonal studies and cell size and Fucci reporter fluorescence measured across several time points where the cells were reaching DD to estimate the accuracy of small cell gates to classify cellular quiescence (Supplementary Fig. 2). Forwardscatter side scatter profiles were used to set small cell gates (Supplementary Fig. 2, left columns) then Fucci fluorescence used to gauge the proportion of incorrectly classified cells (that is, FucciG^{+} cells that fell within the ‘small’ gate and FucciR^{+} quiescent cells that fell within the ‘large’ gate). In this example, 3.3%, 2.9% and 4.7% of cells were incorrectly classified by sizebased gating at the 50.5, 66 and 73 h timepoints, respectively (Supplementary Fig. 2). Extrapolating these error rates to the data shown in Fig. 3 we can estimate that the quiescence status of 165 of the 171 clones in this example has been correctly classified. Collectively, along with previous findings these results indicate that small cell size is an accurate method to estimate cellular quiescence in these studies.
Population DD measurements
The definition and methods by which DD can be estimated during a population response have been published previously^{9}. Briefly, the cohort number (an estimate of the number of starting cells whose progeny are contributing to the response at a time point) was calculated by dividing the cell number per division by 2^{i}, where i is the cell’s generation. The population mean division number was calculated as the arithmetic mean of the cohort numbers at each time point. Assuming little death, the mean division number will increase in time, plateauing at the point where the cells reach DD. Thus, the population mean division destiny (mDD) was estimated as the maximum mean division number measured over all the time points.
Clonal DD calculations
The maximum and minimum generation numbers for a clone were defined as the largest and smallest generation detected within a clone. The clonal range was calculated as the maximum less minimum generation number. Tcell clones were defined as having reached DD based on small cell size^{9,12,20} gated from FSC/SSC profiles of control Tcell populations (Fig. 2f). To determine the mDD for individual clones, the data were cohortnormalized as described for population data. With initial clones being in generation 0, n_{i} being the number of cells in the clone that experience DD in generation i and being the cohortnormalized number of progeny cells in generation i, the proportion of the clone reaching DD (that is, becoming quiescent (qui)) in each division was normalized to exclude cells lost due to incomplete recovery using the following equation:
Note that after renormalization for each clone. The mDD for a clone was calculated as follows:
The maximum DD (maxDD) for a clone was defined to be the largest generation observed within a clone in which all the cells had reached DD. Clones were analysed for DD properties in Figs 4 and 5 and Supplementary Figs 5–7 if all progeny cells were considered to have reached DD based on small cell size.
The betabinomial model and clonal range data
For each of the four stimulation conditions, the following computations were performed to determine the clonal range distributions reported in Fig. 4c and Supplementary Fig. 6c. As described in the main text, the conditional probability that a cell progresses to a DD past generation k, given it got to generation k, p_{k}, was determined from the data. All potential full trees, that is, trees for which all cells are fully sampled, of a given depth were identified by brute force enumeration. Letting t_{i} be the number of DD cells in generation i for such a full tree, T, the number of cells that have not yet reached DD by generation i can be determined as . With B(n,kp,ρ) denoting the betabinomial distribution for picking k objects out of n, parameterized by probability p and correlation ρ, the likelihood of the full tree is . For any subtree, S of T, that is, such that s_{i} ≤ t_{i} for all i, the likelihood of S given the sampling probability r is . Finally, the probability of observing range f is
where χ is the indicator function and the sum is over all full trees T and all subtrees S of the full tree T, and Range(S) is the range of the subtree S. The perstimulation condition bestfit values of ρ displayed in Fig. 4c and Supplementary Fig. 6c were the maximum likelihood estimates identified by custom Python and MATLAB code.
A mathematical framework for the addition of family trees
To investigate whether the effect of stimulatory signals were independently integrated by families, it was necessary to describe the addition or concatenation of family trees. If signals are administered sequentially, a natural definition is to append the family tree generated by the second signal to the DD cells of the family tree generated by the first. If the DD of all cells within the tree generated by the first signal is g_{1} and the DD of all cells in the tree generated by the second is g_{2}, then the sum of two trees will result in one where every cell has a DD of g_{1}+g_{2} (Fig. 1d, top panel) irrespective of the order of signal administration. If there is variation of DD of cells within each family tree, however, then even with sequential signal administration the resulting tree will differ depending on the order of administration (Fig. 1d, bottom panel).
Despite the noncommutativity of the tree shape, the generation of quiescent cells in the tree created by the sum does not depend on the particulars of the addition and can be determined from knowledge of the DD of cells in each tree without reference to the tree structure. This desirable property extends to the circumstances of nonsequential administration or action of signals. If two or more mitogenic signals are added to culture simultaneously, there are many possible tree additions depending on the time and place in the clonal tree these signals provide their contribution. An example of the possible clonal outcomes from different permutations of interlacing signal addition is illustrated in Supplementary Fig. 1. The fundamental premise of this definition of additivity is that the cells in the summed tree experience the expansion aspect of each signal once.
That the generation of quiescent cells in the summed tree is invariant to the particulars of the tree addition is established by the following result. If x and y are two vectors whose ith components, x_{i} and y_{i}, report the number of cells in that family tree whose DD is in generation i, then the equivalent vector for the summed tree, irrespective of how the interlacing of trees is done, is given by the convolution of the vectors x and y, v=x*y, where .
To see this, note we have a correspondence between a family tree and a directed tree by identifying the progenitor with the root vertex and the quiescent cells with the leaves of the graph. For any directed tree, we can associate to it a generating function for its leaves^{42}:
where x_{i} is the number of quiescent cells in generation i and s is a real number.
Given two trees with generating functions X(s) and Y(s), the generating function of the tree created by appending a copy of the second tree to each quiescent cell of the first tree is X(s)Y(s). This can be seen by observing that for each quiescent cell in the first tree of generation i, in the appended tree we now have a contribution to the generating function of , as every quiescent cell in the first tree gives rise to quiescent cells of the second tree, but with i added to their generation. While appending copies of the second tree to the quiescent cells of the first may not result in a tree that is isomorphic to the tree created by appending copies of the first tree to the second tree, they both have generating functions X(s)Y(s). The ith coefficient of this polynomial corresponds to the number of quiescent cells in generation i in the new tree and algebra shows that it is , as stated above.
Having established the result for appending copies of one tree to the final cells of the other, the next step is the situation where the whole second tree is inserted at a finalcell partition of vertices of the first tree. Let {n_{j}: j=1,…,J} be a collection of vertices in the first tree whose descendants form a partition of all of the final cells of the original tree. If g(j) denotes the generation of the vertex n_{j} and X_{j}(s) denotes the generating function of the number of quiescent cells in each generation of the subtree rooted at n_{j}, due to the descendent partition requirement, we have
Inserting the second tree at each vertex n_{j} and endappending copies of the remaining first tree results in a generating function Y(s)X_{j}(s) by the earlier result. Thus the overall generating function is again
and the number of cells in DD in each generation is the same as before. Extending the result to more general interlacing follows arguments along the same lines recursively. Thus, no matter how the additive signal integration occurs, the DD of the cells of an added tree can be determined by knowing the DD of the cells in the trees to be summed, which is the information available from the multiplex method.
Linearity of mDD and maxDD
Within this framework of tree addition, the summary statistics mDD and maxDD can be shown to all be linear functions. Consider two trees described by vectors x and y. For maxDD of the summed tree, we have
and this maximum is attained when i=maxDD(x)+maxDD(y). Linearity of mDD follows directly from an expansion of terms.
Testing clonal level independence of signal integration
Figure 4a shows that each stimulation environment results in heterogeneous family trees and so must be regarded as stochastic. As the statistics maxDD and mDD are linear, if primary and costimulatory signal integration was independent at the level of clones, then the distribution of those statistics for a combination of signals would be the convolution of the statistics taken from individual costimulatory environments. It is not possible to directly measure the expansion effect of these costimulatory signals in isolation, as they require primary stimulation, achieved in this case with N4. Regardless, under the hypothesis of independent signal integration, the distribution of maxDD(N4+αCD28)+maxDD(N4+hIL2) should equal that of maxDD(N4)+maxDD(N4+αCD28+hIL2). Along with the same result using mDD, that is what we compare.
Estimating the CDF of a sum of independent random variables
The maximum likelihood estimator (MLE) for the cumulative distribution function (CDF)^{43} of the sum of two independent random variables, given observations of each of them, is the convolution of their empirical CDFs (eCDFs). That is, given independent and identically distributed observations of and , we have
Thus the MLE for the CDF of X+Y given n observations of X and m observations of Y is the convolution of the eCDF of X with the eCDF of Y:
where χ(x_{i}+y_{j}≤z) is 1 if x_{i}+y_{j}≤z and 0 otherwise.
To determine the eCDF of the mDD and maxDD of a sum of two conditions assuming that the DD influence of the signals was independent, we evaluated the eCDF for each of the signals and convolved those using custom software executed in Matlab and Python to obtain the MLE CDF for the summed condition. This procedure led to Fig. 5 and Supplementary Fig. 7.
Bootstrap confidence intervals
The reported asymmetric 95% confidence Intervals (CIs) were generated by creating bootstrap samples of each individual condition, determining their eCDFs^{44}, convolving those bootstrap eCDFs across two conditions to obtain an estimate of the CDF of the impact of the summed signals, and using percentile bootstrap. Given observations x_{1},…,x_{n} and of y_{1},…,y_{m} of, say, maxDD of two conditions, we created bootstrap samples of each data set and determined the MLE of the CDF of their sum for k=1,…,K. To determine the lower, L(z), and upper, U(z), CIs at each point z of the MLE of the CDF we solve the following minimization problem
Test for equality of convoluted distributions
Pearson’s χ^{2}test of independence is a classic tool that assesses whether one can reject the hypothesis that two discrete random variables X and A, with probability vectors x and a, respectively, are equally distributed. Assessing whether X+Y is equally distributed as A+B based on n_{X},n_{Y},n_{A},n_{B,} observation of four discrete independent random variables with probability vectors the hypothesis to be tested becomes
where * denotes convolution. As the covariance structure of x*y is no longer that of a multinomial, Pearson’s statistic is no longer χ^{2} distributed and another test needs to be developed. We achieve this via Theorem 2 of ref. 45.
Under H_{0}, it can be shown that the sequence , created from empirical observations, is centred and normally distributed with a covariance matrix Σ, determined below, that is distinct from the covariance matrix in the usual multinomial test of independence. Using a consistent estimator of a Moore–Penrose pseudo inverse Σ^{+,e} of Σ, the statistic
is χ^{2} distributed with rank(Σ)=trace(Σ^{+}Σ) degrees of freedom. The test’s P value is
To establish these results, we used the central limit theorem^{46} and independence of X and to verify that
is asymptotically centred and normally distributed with covariance matrix , a block diagonal matrix where c_{Y}=n_{Y}/n_{X}. Applying the delta method^{46} to (X/n_{X}, Y/n_{Y}) with the convolution operation,
is asymptotically centred and normally distributed with covariance matrix where and (T_{Y})_{i,j}=d(u*v)_{i}/dv_{j}_{(u,v)}=_{(x,y)}. Similarly,
is asymptotically centred and normally distributed with covariance matrix , where c_{A}=n_{A}/n_{X} and c_{B}=n_{B}/n_{X}. We apply once more the delta method to the joint vector (X Y/(n_{X}n_{Y})−x y, A B/(n_{A}n_{B})−a b, taking their difference, giving
is asymptotically centred and normally distributed with covariance matrix . Thus the covariance matrix described above has the form . As consequence of Theorem 2 of ref. 45, we have that S=VΣ^{+,e}V^{′} is χ^{2} distributed with rank(Σ) degrees of freedom, where Σ^{+,e} is a consistent estimator of the pseudo inverse Σ^{+} of Σ, which, assuming consistent ranks, can be obtained by substituting x, y, a, b with their consistent estimators into Σ and evaluating a pseudo inverse of it.
As with all categorical hypothesis tests, for practical use each category needs to have a sufficient number of observations to ensure accuracy of the asymptotic normality approximation and categories need to be combined if the data are too sparse. For the convolution test, this is achieved post convolution by projecting each convolution to a common categorization and then taking the vector difference. As projection is a linear operator, under the null hypothesis, the resulting difference is an asymptotically centred normal distribution whose covariance can be determined. Hence a χ^{2} statistic can be created by use of the covariance’s pseudoinverse as above.
For maxDD, no combining of categories was necessary. For mDD, data lying between two consecutive integers, (i,i+1), were binned into a single category. Thus the 11 bins used for mDD were {2}, (2,3), {3}, (3,4), {4}, (4,5), {5}, (5,6), {6}, (6,7)[7,+∞).
Estimating clonal contributions to in vivo population DD
To calculate the percentage contribution of clonal families to the magnitude of the total response (Supplementary Fig. 10), it was assumed that all progeny cells would adopt a concordant DD. The probability of a clone reaching DD in a given division was obtained from Cyton fitting to the OTI/FucciRG CD8^{+} T cell in vivo influenza (HKx31OVA) infection data in Fig. 1d,e and Supplementary Table 1 of ref. 9. The discretized probability function was multiplied by the mean initial cell number for the two experiments (mN_{0}=1,808, Supplementary Table 1 of ref. 9) and only divisions that contained at least one clone were used to determine clonal family contribution to response magnitude (that is, divisions 4–19). The probabilities in each division were normalized so that the discretized probability distribution (f_{i}) for i∈[4,19] summed to 1. The number of progeny cells produced by clones reaching DD in division i was corrected to reintroduce the effects of cell expansion as follows:
The percentage contribution to the total response magnitude of progeny cells reaching DD in each division was calculated as follows:
This was then plotted as a cumulative function against the percentage of the total clones that generated these cells.
Inference of DD distribution from in vivo clonal studies
The percentage contribution of clonal families to the magnitude of the total response was obtained directly from ref. 2. To estimate the DD distribution for this in vivo clonal data, we assumed that in vivo DD was concordant and that minimal cell death had occurred at the time point measured. We estimated the DD as log_{2}(N), where N is the total number of progeny cells detected per clone. Clonal DD was rounded up to the next integer value and binned for every second division.
Code availability
The computer codes that are used in this study are available from the corresponding authors on request.
Data availability
The data that support the findings of this study are available from the corresponding author upon request.
Additional information
How to cite this article: Marchingo, J. M. et al. Tcell stimuli independently sum to regulate an inherited clonal division fate . Nat. Commun. 7, 13540 doi: 10.1038/ncomms13540 (2016).
Publisher's note: Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
References
 1
Moon, J. J. et al. Naive CD4(^{+}) T cell frequency varies for different epitopes and predicts repertoire diversity and response magnitude. Immunity 27, 203–213 (2007).
 2
Buchholz, V. R. et al. Disparate individual fates compose robust CD8^{+} T cell immunity. Science 340, 630–635 (2013).
 3
Gerlach, C. et al. Heterogeneous differentiation patterns of individual CD8^{+} T cells. Science 340, 635–639 (2013).
 4
Plumlee, C. R., Sheridan, B. S., Cicek, B. B. & Lefrançois, L. Environmental cues dictate the fate of individual CD8(^{+}) T cells responding to infection. Immunity 39, 347–356 (2013).
 5
Tubo, N. J. et al. Single naive CD4^{+} T cells from a diverse repertoire produce different effector cell types during infection. Cell 153, 785–796 (2013).
 6
Stemberger, C. et al. A single naive CD8^{+} T cell precursor can develop into diverse effector and memory subsets. Immunity 27, 985–997 (2007).
 7
Gerlach, C. et al. One naive T cell, multiple fates in CD8^{+} T cell differentiation. J. Exp. Med. 207, 1235–1246 (2010).
 8
Rohr, J. C., Gerlach, C., Kok, L. & Schumacher, T. N. Single cell behavior in T cell differentiation. Trends Immunol. 35, 170–177 (2014).
 9
Marchingo, J. M. et al. Antigen affinity, costimulation, and cytokine inputs sum linearly to amplify T cell expansion. Science 346, 1123–1127 (2014).
 10
StarbeckMiller, G. R., Xue, H. & Harty, J. T. IL12 and type I interferon prolong the division of activated CD8 T cells by maintaining highaffinity IL2 signaling in vivo. J. Exp. Med. 211, 105–120 (2014).
 11
Zehn, D., Lee, S. Y. & Bevan, M. J. Complete but curtailed Tcell response to very lowaffinity antigen. Nature 458, 211–214 (2009).
 12
Hawkins, E. D., Markham, J. F., McGuinness, L. P. & Hodgkin, P. D. A singlecell pedigree analysis of alternative stochastic lymphocyte fates. Proc. Natl Acad. Sci. USA 106, 13457–13462 (2009).
 13
Turner, M. L., Hawkins, E. D. & Hodgkin, P. D. Quantitative regulation of B cell division destiny by signal strength. J. Immunol. 181, 374–382 (2008).
 14
Chang, J. T. et al. Asymmetric T lymphocyte division in the initiation of adaptive immune responses. Science 315, 1687–1691 (2007).
 15
Reiner, S. L. & Adams, W. C. Lymphocyte fate specification as a deterministic but highly plastic process. Nat. Rev. Immunol. 14, 699–704 (2014).
 16
Duffy, K. R. & Hodgkin, P. D. Intracellular competition for fates in the immune system. Trends Cell Biol. 22, 457–464 (2012).
 17
Hodgkin, P. D., Dowling, M. R. & Duffy, K. R. Why the immune system takes its chances with randomness. Nat. Rev. Immunol. 14, 711 (2014).
 18
Lyons, B. A. & Parish, C. R. Determination of lymphocyte division by flow cytometry. J. Immunol. Methods 171, 131–137 (1994).
 19
Quah, B. J. C. & Parish, C. R. New and improved methods for measuring lymphocyte proliferation in vitro and in vivo using CFSElike fluorescent dyes. J. Immunol. Methods 379, 1–14 (2012).
 20
Kinjyo, I. et al. Realtime tracking of cell cycle progression during CD8(^{+}) effector and memory Tcell differentiation. Nat. Commun. 6, 6301 (2015).
 21
Dowling, M. R. et al. Stretched cell cycle model for proliferating lymphocytes. Proc. Natl Acad. Sci. USA 111, 6377–6382 (2014).
 22
Duffy, K. R. et al. Activationinduced B cell fates are selected by intracellular stochastic competition. Science 335, 338–341 (2012).
 23
Wensveen, F. M. et al. Apoptosis threshold set by Noxa and Mcl1 after T cell activation regulates competitive selection of highaffinity clones. Immunity 32, 754–765 (2010).
 24
Gottschalk, R. A. et al. Distinct influences of peptideMHC quality and quantity on in vivo Tcell responses. Proc. Natl Acad. Sci. USA 109, 881–886 (2012).
 25
Feinerman, O. et al. Singlecell quantification of IL2 response by effector and regulatory T cells reveals critical plasticity in immune response. Mol. Syst. Biol. 6, 437 (2010).
 26
Smith, K. A. & Cantrell, D. A. Interleukin 2 regulates its own receptors. Proc. Natl Acad. Sci. USA 82, 864–868 (1985).
 27
Butz, E. A. & Bevan, M. J. Massive expansion of antigenspecific CD8^{+} T cells during an acute virus infection. Immunity 8, 167–175 (1998).
 28
MuraliKrishna, K. et al. Counting antigenspecific CD8 T cells: a reevaluation of bystander activation during viral infection. Immunity 8, 177–187 (1998).
 29
De Boer, R. J., Homann, D. & Perelson, A. S. Different dynamics of CD4^{+} and CD8^{+} T cell responses during and after acute lymphocytic choriomeningitis virus infection. J. Immunol. 171, 3928–3935 (2003).
 30
Buchholz, V. R., Schumacher, T. N. & Busch, D. H. T cell fate at the singlecell level. Annu. Rev. Immunol. 34, 65–92 (2016).
 31
Chen, L. & Flies, D. B. Molecular mechanisms of T cell costimulation and coinhibition. Nat. Rev. Immunol. 13, 227–242 (2013).
 32
Mescher, M. F. et al. Signals required for programming effector and memory development by CD8^{+} T cells. Immunol. Rev. 211, 81–92 (2006).
 33
King, C. G. et al. T cell affinity regulates asymmetric division, effector cell differentiation, and tissue pathology. Immunity 37, 709–720 (2012).
 34
Curtsinger, J. M. & Mescher, M. F. Inflammatory cytokines as a third signal for T cell activation. Curr. Opin. Immunol. 22, 333–340 (2010).
 35
Voisinne, G. et al. T cells integrate local and global cues to discriminate between structurally similar antigens. Cell Rep. 11, 1208–1219 (2015).
 36
Schlub, T. E. et al. Divisionlinked differentiation can account for CD8^{+} Tcell phenotype in vivo. Eur. J. Immunol. 39, 67–77 (2009).
 37
Gett, A. V. & Hodgkin, P. D. Cell division regulates the T cell cytokine repertoire, revealing a mechanism underlying immune class regulation. Proc. Natl Acad. Sci. USA 95, 9488–9493 (1998).
 38
June, C. H., Riddell, S. R. & Schumacher, T. N. Adoptive cellular therapy: a race to the finish line. Sci. Transl. Med. 7, 280ps7 (2015).
 39
Restifo, N. P., Dudley, M. E. & Rosenberg, S. A. Adoptive immunotherapy for cancer: harnessing the T cell response. Nat. Rev. Immunol. 12, 269–281 (2012).
 40
Tomura, M. et al. Contrasting quiescent G0 phase with mitotic cell cycling in the mouse immune system. PLoS ONE 8, e73801 (2013).
 41
SakaueSawano, A. et al. Visualizing spatiotemporal dynamics of multicellular cellcycle progression. Cell 132, 487–498 (2008).
 42
Wilf, H. S. Generatingfunctionology Academic Press (1990).
 43
Billingsley, P. Probability and Measure 3rd edn Wiley (2008).
 44
Beran, R. Bootstrap methods in statistics. Jahresber. Deutsch. Math. Verein. 86, 14–30 (1984).
 45
Moore, D. S. Generalized inverses, Wald's method, and the construction of Chisquared tests of fit. J. Am. Stat. Assoc. 72, 131–137 (1977).
 46
Serfling, R. J. Approximation Theorems of Mathematical Statistics Wiley (1980).
Acknowledgements
We thank the Busch and Schumacher laboratories for providing raw data from their published work for additional analyses in Supplementary Fig. 10, Philippe Bouillet for Bcl2l11^{−/−} mice and Manuela Hancock for technical assistance. Fucci Red and Fucci Green mice were provided by the Riken BioResource Centre through the National BioResource Project of the Ministry of Education, Culture, Sports, Science, and Technology of Japan. This work was supported by the National Health and Medical Research Council of Australia via Project Grant 1010654, Program Grant 1054925 and a fellowship to P.D.H. as well as an Australian Government National Health and Medical Research Council Independent Research Institutes Infrastructure Support Scheme Grant 361646. K.R.D. was supported by Science Foundation Ireland Grant 12IP1263. The research leading to these results has received funding from the European Union Seventh Framework Programme (FP7/2007–2013) under grant agreement 317040 (QuanTI). We also received support from the Victorian State Government Operational Infrastructure scheme. J.M.M. was the recipient of an Australian Postgraduate Award, an Edith Moffat Scholarship from The Walter and Eliza Hall Institute and Sydney Parker Smith Postdoctoral Research Fellowship from the Cancer Council of Victoria.
Author information
Affiliations
Contributions
J.M.M. performed experiments, analysed and interpreted data and cowrote manuscript. K.R.D. and P.D.H. codesigned the multiplex assay, oversaw study planning, analysis, data interpretation and writing the manuscript. G.P. and K.R.D. developed and performed novel statistical analyses on clonal data. A.K. contributed to data analysis and interpretation. S.H. contributed to experimental planning and data interpretation.
Corresponding authors
Ethics declarations
Competing interests
The authors declare no competing financial interests.
Supplementary information
Supplementary Information
Supplementary Figures 110 and Supplementary References (PDF 1039 kb)
Rights and permissions
This work is licensed under a Creative Commons Attribution 4.0 International License. The images or other third party material in this article are included in the article’s Creative Commons license, unless indicated otherwise in the credit line; if the material is not included under the Creative Commons license, users will need to obtain permission from the license holder to reproduce the material. To view a copy of this license, visit http://creativecommons.org/licenses/by/4.0/
About this article
Cite this article
Marchingo, J., Prevedello, G., Kan, A. et al. Tcell stimuli independently sum to regulate an inherited clonal division fate. Nat Commun 7, 13540 (2016). https://doi.org/10.1038/ncomms13540
Received:
Accepted:
Published:
Further reading

Differential expansion of T central memory precursor and effector subsets is regulated by division speed
Nature Communications (2020)

Sample path properties of the average generation of a Bellman–Harris process
Journal of Mathematical Biology (2019)

T cell cytolytic capacity is independent of initial stimulation strength
Nature Immunology (2018)
Comments
By submitting a comment you agree to abide by our Terms and Community Guidelines. If you find something abusive or that does not comply with our terms or guidelines please flag it as inappropriate.
